03E109210L Timing Case
- 03E109210ANot stocked
Dec 2003 - 03E109210ENot stocked
Apr 2004 - 03E109210GNot stocked
Jun 2008 - 03E109210LThis pageNot stocked
Jan 2020 - 03E109210QCurrent number
Special order item. Delivery time may vary.
About This Part
Superseded part number
This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VOLKSWAGEN is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
8 vehiclesTiming Case — locate Timing Case in the official exploded view and explore the surrounding assembly.
Parts in this assembly31
- 1APart N90547401
- 2Cover N0119182
- 3Cover 036103113A
- 4Cover N0119012
- 5Part 03E109210Q
- 5Case 03E109210K
- 5Part 03E109210P
- 6Part D174003A2
- 7Part N10617101
- 8Seal 038103085E
- 9Separator 03C103464A
- 10Screw N10248003
- 11Screw N10582103
- 12Bolt N10700201
- 13Screw N90870504
- 14Screw N10552302
- 18Washer 03D103323
- 19Bolt N90954902
- 20Sleeve 022103139B
- 21Oil Sump 03D103601G
- 22Screw N0160276
- 23Seal Ring N0138492
- 24Screw N10226103
- 24Bolt N10451405
- 26Seal D176600A1
- 27Seal 021103051C
- 28Cover 03D103647C
- 30Valve 03E103201C
- 31Seal Ring N90613201
- 32Screw N10709301
- 32Screw N90823601
Vehicle fitment table8
Europe (8)
| Vehicle | Years | Pos. | Qty | PR |
|---|---|---|---|---|
| Fabia Ambiente | 2009-2013 | 5 | 1 | |
| Ibiza Reference | 2008-2011 | 5 | ||
| Polo | 2008-2009 | 5 | 1 | D21 |
| ROOMSTER 06> | 2006- | 5 | 1 | |
| POLO | 2005- | 5 | 1 | |
| FABIA/COMBI 05> | 2004- | 5 | 1 | |
| POLO | 2001-2005 | 5 | ||
| FABIA/COMBI | 1999-2004 | 5 | 1 | QG0 |
Diagrams & fitment data powered by oemdiagrams.com
Timing Case is fitted on: Fabia Ambiente 2009-2013; Ibiza Reference 2008-2011; Polo 2008-2009; ROOMSTER 06> 2006-; POLO 2005-; FABIA/COMBI 05> 2004-; POLO 2001-2005; FABIA/COMBI 1999-2004.
