United States
03F109210C Timing Case
- 03F109210BNot stocked
Mar 2011 - 03F109210CThis pageNot stocked
Jan 2012 - 03F109210DCurrent number
Special order item. Delivery time may vary.
About This Part
Superseded part number
This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for SEAT is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
7 vehiclesTiming Case — locate Timing Case in the official exploded view and explore the surrounding assembly.
Parts in this assembly25
- 1Cylinder Block 03F103101
- 2Cover N0119096
- 3Cover 03C103113
- 4Cover 036103113
- 5Cover N10218603
- 6Sleeve 03C103143
- 7Valve 03F103156A
- 7Valve 03F103156
- 8Part N0432072
- 9Screw N90856005
- 10Vent 03C103157A
- 11Flange 036103171B
- 12Bolt N90842402
- 14Radial Sea 038103085C
- 15Seal D176501A1
- 16Socket N10734501
- 17Socket N10734401
- 18Oil Sump 03C103601BK
- 19Bolt N90813202
- 21Seal D176600M1
- 22Screw N10248003
- 23Separator 03F103464C
- 24Bolt N10748001
- 25Screw N10470703
- 26Spacer Pl 03C103551L
Vehicle fitment table7
Europe (7)
| Vehicle | Years | Pos. | Qty | PR |
|---|---|---|---|---|
| Rapid | 2012-2022 | 13 | 1 | |
| Ibiza Reference | 2011-2012 | 13 | 1 | |
| Altea XL Reference | 2010-2013 | 13 | 1 | DB0 |
| golf estate | 2009-2013 | 13 | 1 | |
| Polo | 2009-2012 | 13 | 1 | DB0 |
| Audi A3 Sportback | 2008-2013 | 13 | 1 | DB0 |
| Audi A3 Cab. 2.0 TDI | 2007-2013 | 13 | 1 | DB0 |
Diagrams & fitment data powered by oemdiagrams.com
Timing Case is fitted on: Rapid 2012-2022; Ibiza Reference 2011-2012; Altea XL Reference 2010-2013; golf estate 2009-2013; Polo 2009-2012; Audi A3 Sportback 2008-2013; Audi A3 Cab. 2.0 TDI 2007-2013.
