Chain Sprocket exploded parts diagram — Audi A4/S4/Av./qu. 05> · 2005-, position 1A
Exploded view
Audi A4/S4/Av./qu. 05> · 2005- · position 1AFull diagram ↓
03G105173

03G105173 Chain Sprocket

£173.61
£143.48 excl. VAT
Supersession roadforks into 7
  1. 03G105173This pageNot stocked
    Aug 2008
  2. 03G198998FNot stocked
    Nov 2008
  1. 03G103305CCurrent number
  2. N91121301Current number
  3. N90977502Current number
  4. 03G105212DCurrent number
  5. 038103085ECurrent number
  6. 03G103295ALCurrent number
  7. 03G103603AHDiscontinued
    Jul 2026
Availability: No longer supplied under this number

Special order item. Delivery time may vary.

About This Part

Superseded part number

This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.

Order Processing & Delivery

This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VOLKSWAGEN is typically 3–8 business days before dispatch.

Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.

* Delivery times are estimates and may vary based on manufacturer availability and your location.

Verify Vehicle Fitment

To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.

Contact us with your VIN
Genuine OEM Parts
Direct from manufacturer
Secure Ordering
Safe and protected checkout

Parts diagram & fitment

2 vehicles

Chain Sprocket — locate Chain Sprocket in the official exploded view and explore the surrounding assembly.

Parts in this assembly22
Vehicle fitment table2

Europe (2)

VehicleYearsPos.QtyPR
Audi A4/S4/Av./qu. 05>2005-1A1DA1,DA6,DA7,D0M,D3X,G0K,G0L,G0Z,MS9
Audi A6/S6/Avant/qu. 05>2004-1A1D3X,G0K,G0Z,MS9

Diagrams & fitment data powered by oemdiagrams.com

Chain Sprocket is fitted on: Audi A4/S4/Av./qu. 05> 2005-; Audi A6/S6/Avant/qu. 05> 2004-.
