03H121008K Coolant Pump With Sealing Ring
- 03H121008Not stocked
Mar 2010 - 03H121008BNot stocked
Jan 2012 - 03H121008DNot stocked
Nov 2015 - 03H121008HNot stocked
Jun 2017 - 03H121008KThis pageNot stocked
Jun 2020 - 03H121008MCurrent number
Special order item. Delivery time may vary.
About This Part
Superseded part number
This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VOLKSWAGEN is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
3 vehiclesCoolant Pump With Sealing Ring — locate Coolant Pump With Sealing Ring in the official exploded view and explore the surrounding assembly.
Parts in this assembly25
- 2Seal Ring 03H121119
- 3Pulley 021121031D
- 4Screw N90544203
- 5Screw N10526802
- 10Housing 03H121117B
- 11Seal Ring WHT005190
- 12Seal Ring WHT000862
- 14Coolant Rg 03H121113E
- 15Seal Ring WHT000863
- 16Cover 03H121121D
- 17Screw N10611201
- 18Connection 03H121133
- 19Spring 03H121142
- 20Spring 032121142
- 21Seal Ring N90316801
- 22Sender 05C919501
- 23Seal Ring 03H121041
- 24Bolt N91054101
- 25Connection 03H121131A
- 26Seal Ring 03H121041A
- 27Screw N90292903
- 28Seal Ring 095323971
- 30Connection 03H121145A
- 31Seal Ring 03H121041B
- 32Bolt N91071701
Vehicle fitment table3
Europe (1)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| Touareg BlueMotion | 2014-2018 | 1 | 1 | D3B |
Other markets (2)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| Atlas Cross Sport | 2019-2023 | 1 | 1 | ||
| Atlas | 2016-2023 | 1 | 1 |
Diagrams & fitment data powered by oemdiagrams.com
Coolant Pump With Sealing Ring is fitted on: Touareg BlueMotion 2014-2018; Atlas Cross Sport 2019-2023; Atlas 2016-2023.
