03L131512BL Radiator
- 03L131512BBNot stocked
Feb 2011 - 03L131512BLThis pageNot stocked
Apr 2012 - 03L131512CHNot stocked
May 2012 - 03L131512CFNot stocked
Apr 2014 - 03L131512DQCurrent number
Special order item. Delivery time may vary.
About This Part
Superseded part number
This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for SEAT is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
8 vehiclesRadiator — locate Radiator in the official exploded view and explore the surrounding assembly.
Parts in this assembly34
- 1Part 03L131512CF
- 1Part 03L131512CH
- 1Part 03L131512DQ
- 2Bolt N10196103
- 3Bolt N10405604
- 4Pipe 03P131521B
- 4Pipe 03P131521E
- 5Seal 04L131547S
- 6Ut Hexagon Nut Self-locking Hexagon Nut N90894601
- 7Seal 03K131547C
- 8Screw N91032702
- 9Clamp 070131548C
- 10Pipe 03L131521R
- 13Pipe 03P131521A
- 15Heat Insul 03L131531A
- 20Hose 03L131605M
- 21Screw N10170303
- 22Hose 03L131055DP
- 23Valve 1K0906283A
- 24Retaining 03L131529F
- 25Bolt N10406504
- 26Retaining 03L131529G
- 28Clip 6Q0131927
- 30Pipe 03L131605N
- 31Hose 03L131055DQ
- 33Collar Nut N01508210
- 34Converter 1K0906627B
- 35Spacer 052129734
- 36Retaining 1K0906215S
- 37Grommet 046131887
- 38Bracket 6X0971845B
- 39Plate 046130405
- 40Cable Tie 3D0971838N
- 41Binder 4A0820199
Vehicle fitment table8
Europe (8)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| Audi Q3 quattro | 2011-2015 | 1 | |||
| Audi TTS Coupe 2.0 | 2010-2014 | 1 | |||
| Altea XL Reference | 2010-2013 | 5 | 1 | D | |
| Leon Stylance | 2010-2012 | 5 | 1 | D | |
| Audi A3 Sportback | 2008-2013 | 5 | 1 | D | |
| Passat CC | 2008-2012 | 5 | |||
| jetta | 2008-2011 | 5 | 1 | ||
| TIGUAN 08> | 2007- | 5 | 1 |
Diagrams & fitment data powered by oemdiagrams.com
Radiator is fitted on: Audi Q3 quattro 2011-2015; Audi TTS Coupe 2.0 2010-2014; Altea XL Reference 2010-2013; Leon Stylance 2010-2012; Audi A3 Sportback 2008-2013; Passat CC 2008-2012; jetta 2008-2011; TIGUAN 08> 2007-.
