059121063C Coolant Hose
This is a catalog item (special order). Delivery time may vary.
Special order item. Delivery time may vary.
About This Part
Available for Purchase
This part is available to order directly from the manufacturer. While it's not currently in our warehouse, we can source it for you and have it shipped to your location.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VAG is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINShipping details
- Shipping weight
- 28 g
- Shipping size (L × W × H)
- 24 × 5 × 4 cm
- Country of origin
- Germany
- Customs (HS) code
- 40093100
Parts diagram & fitment
5 vehiclesCoolant Hose — locate Coolant Hose in the official exploded view and explore the surrounding assembly.
Parts in this assembly48
- 1Water Pipe 059121071BF
- 2Seal Ring N90275302
- 3Bolt N10451405
- 4Bolt N10124306
- 5Hose 059121105C
- 6Water PipeLeft059121507AD
- 6AWater PipeLeft059121511H
- 6BHoseLeft059121062
- 7Bolt N90483204
- 8Seal Ring N0138042
- 9Part WHT000508
- 10Bolt N10632002
- 11Hose 059121058J
- 12Bolt N90529302
- 13Water Pipe 059121044F
- 13Water Pipe 059121044B
- 13AHose 059121088
- 14Hose 059121052G
- 15Water PipeRight059121064E
- 16Cover 059121155
- 16Cover 059121155C
- 16ASeal Ring N91008401
- 17Screw N10170303
- 18Hose 059121053F
- 20Hose 059121057H
- 21Bracket 059131425A
- 22Seal Ring N90809102
- 23Hose 7L6122109E
- 24Screw N10626801
- 25Hose 059121104A
- 26Pump 059121012A
- 27Bracket 059103392AC
- 28Screw WHT002306
- 29Hose 059121102D
- 30Hose 7L6122101L
- 30Hose 7L6122101Q
- 31Seal Ring N90933101
- 32Spring 4E0121142
- 34Water Pipe 059121163F
- 35Seal Ring N90365304
- 36Part N90488005
- 37Hose 059121103C
- 38Hose 059121061F
- 39Hose 059121073G
- 40Connection 059121131B
- 40ASeal Ring N90783401
- 41Bolt N10156206
- 42Bracket 057121077
Vehicle fitment table5
Europe (5)
| Vehicle | Years | Pos. | Qty | PR |
|---|---|---|---|---|
| Audi Q7 qu. 3.0 TDI | 2009-2015 | 19 | 1 | TE1 |
| Touareg 08> | 2007- | 19, 23 | 1 | 8GH |
| Audi Q7 07> | 2006- | 19 | 1 | TE1 |
| Touareg | 2005-2006 | 23 | ||
| Touareg | 2003-2005 | 23 | 1 |
Diagrams & fitment data powered by oemdiagrams.com
Coolant Hose is fitted on: Audi Q7 qu. 3.0 TDI 2009-2015; Touareg 08> 2007-; Audi Q7 07> 2006-; Touareg 2005-2006; Touareg 2003-2005.
