Number 22 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Coolant Pipe Assembly, part number 05E122447L. This assembly combines a pipe and hose to facilitate the flow of coolant within the engine's cooling system. It is located at position 22 in the diagram. This part is constructed from durable materials designed to withstand engine temperatures and pressures. Genuine OEM coolant pipes ensure precise routing and connection integrity, preventing leaks and maintaining optimal engine cooling performance.
Catalogue entry: WATER PIPE.
Fitted with: N10451405 BOLT.
Technical details
- Category
- Engine Cooling
- Customs (HS) code
- 40093200
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 40 × 14 × 7 cm
- Shipping weight
- 0.14 kg
Why buy from WW Spares?
- ✓ Genuine OEM inventory sourced directly from factory networks
- ✓ Fitment support from workshop-seasoned parts specialists
- ✓ Global logistics with customs-ready documentation
Need help confirming compatibility? Talk to a specialist
Parts diagram & fitment
24 vehiclesCoolant Pipe With Coolant Hose — locate 05E122447L Volkswagen Coolant Pipe Assembly | Genuine OEM in the official exploded view and explore the surrounding assembly.
Parts in this assembly47
- 1Hose 3WA121049G
- 1Hose 5WA121049L
- 1Hose 5WA121049T
- 1Hose 5WA122101AH
- 3Sender 06A919501A
- 3Bracket 3C0121093D
- 4Spring 025121142
- 5Hose 5WA122051AC
- 5Hose 5WA122051S
- 5Seal Ring N90316801
- 6Adapter N90692901
- 7Bracket 5Q0121093CM
- 8Water Pipe 05E121070
- 9Bolt N10196103
- 10Hose 5WA121109F
- 11Hose 5WA122063A
- 12Water Pipe 05E122447F
- 15Bolt N10451405
- 15Pump 05E965561
- 15Screw N10507201
- 16Bracket 5WA121093F
- 17Hose 5Q0121156E
- 17Rubber Bush 03L121275
- 17Hose 5Q0121156D
- 18Sleeve 03L121199
- 18Coupl Piece 5Q0122291AJ
- 19Coupl Piece 3B0122291B
- 19Coupl Piece 5Q0122291EB
- 19Coupl Piece 5Q0122291S
- 19Bolt WHT003361
- 20Water Pipe 05E121497A
- 20Water Pipe 05E121497E
- 20Bolt N10653102
- 21Seal 04E121687B
- 21Seal 04E121687F
- 22Water Pipe 05E122447AA
- 23Screw N10721401
- 25Water Pipe 05E121064
- 26Clamp N90754202
- 30Screw N10664801
- 31Bolt N10405604
- 40Clamp N90687001
- 41Clamp N90687201
- 42Clamp N90686701
- 43Clamp N90770201
- 44ClampLeftN90686901
- 44ClampRightN90686902
Vehicle fitment table24
Europe (24)
| Vehicle | Years | Pos. | Qty | PR |
|---|---|---|---|---|
| Kodiaq | 2024- | 22 | 1 | |
| passat estate | 2023- | 22 | 1 | |
| Tiguan 2.0 | 2023- | 22 | 1 | |
| Superb Combi | 2023- | 22 | 1 | |
| fabia | 2021- | 22 | 1 | |
| Taigo | 2021-2024 | 22 | 1 | N09 |
| Formentor TSI CUPRA | 2020- | 22 | 1 | |
| Caddy Maxi Kombi | 2020-2024 | 22 | 1 | |
| Kamiq | 2019- | 22 | 1 | |
| Leon style | 2019- | 22 | 1 | |
| Golf 2.0 BlueMotion | 2019-2024 | 22 | 1 | |
| T-Roc convertible 1.5 | 2019-2024 | 22 | 1 | |
| Octavia | 2019-2024 | 22 | 1 | |
| Audi A3 Sportback | 2019-2021 | 22 | 1 | |
| Audi A1 sportback 1.0 | 2018- | 22 | 1 | |
| T-Cross 1,0 | 2018-2024 | 22 | 1 | |
| Audi Q3 quattro | 2018-2019 | 22 | 1 | |
| T-Roc BlueMotion | 2017-2024 | 22 | 1 | |
| Tiguan 2.0 4Motion | 2017-2024 | 22 | 1 | |
| Karoq | 2017-2022 | 22 | 1 | |
| Ateca Style | 2016- | 22 | 1 | |
| Tiguan 2.0 4Motion | 2016-2024 | 22 | 1 | |
| Audi Q2 2.0 TDI | 2016-2018 | 22 | 1 | |
| Touran 2,0 BlueMotion | 2015-2024 | 22 | 1 |
