Genuine OEM Audi Timing Chain Guide Rail, part number 06E109507D. This component is crucial for maintaining the correct alignment and tension of the engine's timing chain. It is typically located within the timing chain assembly, guiding the chain to prevent slack and ensure precise valve timing. Constructed from durable metal with a low-friction polymer surface, it measures 0.255m in length and weighs 0.425 kg. Using a genuine OEM guide rail ensures exact fitment and material quality, critical for the longevity and reliable operation of the engine's timing system.
Catalogue entry: TENSIONER.
Fitted with: 06E109465 timing cha, N10124304 BOLT, N10451409 BOLT, N90362001 SEAL. RING, N10468703 SCREW, N91073701 SCREW.
Technical details
- Category
- Belts, Chains & Tensioners
- Country of origin
- Germany
- Customs (HS) code
- 84099100
- Manufacturer
- Audi
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 25.5 × 13 × 6.3 cm
- Shipping weight
- 0.43 kg
Specifications
As recorded in the manufacturer’s parts catalogue for this part number.
Equipment codes
- D18
PR codes identify the factory option a part belongs to; your vehicle’s are listed on the data sticker in the boot well or service booklet.
Why buy from WW Spares?
- ✓ Genuine OEM inventory sourced directly from factory networks
- ✓ Fitment support from workshop-seasoned parts specialists
- ✓ Global logistics with customs-ready documentation
Need help confirming compatibility? Talk to a specialist
