107201594 Lock Cylinder Without Key
Special order item. Delivery time may vary.
About This Part
Discontinued by the manufacturer
This part number has been discontinued and can no longer be ordered. Contact us and we will look for an alternative.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VOLKSWAGEN is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
21 vehiclesLock Cylinder Without Key — locate Lock Cylinder Without Key in the official exploded view and explore the surrounding assembly.
Parts in this assembly46
- 1Container 1SB201060D
- 1Fuel Tank 1SB201060E
- 1Container 1SB201060F
- 1Container 1SB201060H
- 1Fuel Tank 1SB201060J
- 1Container 1SB201060L
- 1Container 1SB201060M
- 1Container 1SB201060N
- 1Fuel Tank 1SB201060P
- 1Container 1SB201060Q
- 1Container 1SB201060B
- 2Container 1S0201801B
- 2Container 1S0201801A
- 3Pipe 1SB201160
- 4End Piece 1SB201890
- 5Fuel Line 1SB201293A
- 5Fuel Line 1SB201293
- 5AFuel Line 1SB201294A
- 5AFuel Line 1SB201294
- 5BPart 107201594B
- 6Ap Cap Filler Cap Without Lock Cylin- Der For 1H0201553
- 6Part 1J0201550BM
- 6Part 1SB201553A
- 6Cover 1S0201553A
- 7Seal Ring 191201557
- 7Seal Ring 1K0201557A
- 8Line 5Z0201142B
- 8ABush 1J0201048C
- 9Bolt N90693804
- 10Shield Plt 1SB201307A
- 10Shield Plt 1SB201307
- 11Part N91068501
- 12Bolt N10109210
- 12Bolt N90835704
- 13Part 321201375A
- 17Strap 1SB201655
- 18Line 1SB201142
- 20Wedge 1SB201295A
- 21Wedge 5U0201295B
- 22Clip 376201150
- 23Screw N90496802
- 24Filter 1SB201511
- 24Filter JZZ201511C
- 25Washer N90033302
- 26Retainer 5N0201292B
- 27Part N90947201
Vehicle fitment table21
Europe (2)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| up! 1.0 TSI | 2013-2017 | 5B | 1 | ||
| FOX 04> | 2003- | 17 | 1 |
Other markets (17)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| up! 1.0 TSI | 2017-2021 | 5B | 1 | ||
| Crossfox | 2014-2021 | 17 | 1 | ||
| Spacefox | 2014-2019 | 5 | 1 | ||
| Polo Vivo | 2014-2017 | 13 | 1 | 2W4 | |
| Spacefox | 2010-2014 | 5 | 1 | ||
| Polo Vivo | 2010-2014 | 18 | 1 | 2W4 | |
| Crossfox | 2009-2014 | 17 | 1 | ||
| SURAN (FOX MPV) "RA."06> | 2006- | 17 | 1 | ||
| POLO JIN QIN "CN"06> | 2006- | 18 | 1 | 0F2,1A1,1A3,1E1,1X0,2LA,2LC,7PA | |
| POLO JIN QV "CN"06> | 2006- | 18 | 1 | 0F2,1A1,1A3,1E1,2LA,2LC,7PA | |
| AUDI A3 "BR."M.06> | 2005-2006 | 9 | 1 | ||
| POLO CLASSIC "CN"03>06 | 2003-2006 | 18 | 1 | 0F2,1A1,1A3,1E1,1X0,2LA,2LC,7PA | |
| POLO CLASSIC (AUS) "CN"03>06 | 2003-2006 | 18 | 1 | 0F2,1A1,1A3,1E1,1X0,2LA,2LC,7PA | |
| Golf "BR.","USA"03>07 | 2002-2007 | 9 | 1 | PR:2W1 | |
| POLO "CN"02>06 | 2002-2006 | 18 | 1 | ||
| Golf BR/US | 2001-2002 | 9 | 1 | 2W1 | |
| AUDI A3-BRASIL. | 2000-2005 | 9 | 1 |
Platform / generic diagrams (2)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| 1J0 platform | 9 | 1 | |||
| 1J0 platform | 17A | 1 |
Diagrams & fitment data powered by oemdiagrams.com
Lock Cylinder Without Key is fitted on: up! 1.0 TSI 2013-2017; FOX 04> 2003-; up! 1.0 TSI 2017-2021; Crossfox 2014-2021; Spacefox 2014-2019; Polo Vivo 2014-2017; Spacefox 2010-2014; Polo Vivo 2010-2014; Crossfox 2009-2014; SURAN (FOX MPV) "RA."06> 2006-; POLO JIN QIN "CN"06> 2006-; POLO JIN QV "CN"06> 2006-; AUDI A3 "BR."M.06> 2005-2006; POLO CLASSIC "CN"03>06 2003-2006; POLO CLASSIC (AUS) "CN"03>06 2003-2006; Golf "BR.","USA"03>07 2002-2007; POLO "CN"02>06 2002-2006; Golf BR/US 2001-2002; AUDI A3-BRASIL. 2000-2005; 1J0 platform.
