211721619 Leaf Spring
- 281798031Not stocked
May 2002 - 211721619This pageDiscontinued
Mar 2014
Special order item. Delivery time may vary.
About This Part
Discontinued by the manufacturer
This part number has been discontinued and can no longer be ordered. Contact us and we will look for an alternative.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VAG is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINShipping details
- Shipping weight
- 1 g
- Customs (HS) code
- 73201019
Parts diagram & fitment
5 vehiclesLeaf Spring — locate Leaf Spring in the official exploded view and explore the surrounding assembly.
Parts in this assembly28
- 1BPart N0111513
- 1CWasher N01224110
- 1DWasher T00721997
- 1EMounting T00721661A
- 1FWasher N01155811
- 1GShaft T00721609B
- 1JRet Washer N0124342
- 2Cable 2TA721555
- 3Acc Pedal T00721507C
- 4Clamp TAP130651
- 5Bracket TAP130749
- 7Bracket T00721521A
- 8Clip NFE864848AA
- 8AClamp 2TA721993
- 9Part 600721535
- 11Part T12721175
- 12Screw N0147506
- 13Screw N0139655
- 15Part 211721629
- 17Ret Washer N0123292
- 19Cable Tie N0209048
- 20Bolt N01021226
- 21Washer N01152426
- 22Part N01100636
- 23Washer N01166620
- 24Part N0111156
- 26Spring TAP721519
- 27Washer N0115572
Vehicle fitment table5
Europe (5)
| Vehicle | Years | Pos. | Qty |
|---|---|---|---|
| L80 | 1995-1999 | 14 | 1 |
| LT, LT 4x4 (28-55) | 1989-1995 | 16, 13 | 1 |
| LT, LT 4x4 (28-55) | 1982-1989 | 16, 13 | 1 |
| LT 28-40 F>28-d-007273 | 1975-1982 | 16, 13 | 1 |
| Type 2 | 1967-1979 | 11 | 1 |
Diagrams & fitment data powered by oemdiagrams.com
Leaf Spring is fitted on: L80 1995-1999; LT, LT 4x4 (28-55) 1989-1995; LT, LT 4x4 (28-55) 1982-1989; LT 28-40 F>28-d-007273 1975-1982; Type 2 1967-1979.
