3C8121284D Air Guide
- 3C8121284DThis pageNot stocked
Nov 2015 - 3C8121284ECurrent number
Special order item. Delivery time may vary.
About This Part
Superseded part number
This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VOLKSWAGEN is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
1 vehicleAir Guide — locate Air Guide in the official exploded view and explore the surrounding assembly.
RThis part is the Right side
Parts in this assembly21
- 1Ring 1K0121205AD
- 1Ring 1K0121207BB
- 2Air Flap 1K0121223
- 4Ut Hexagon Flange Nut Self-locking Hexagon N90887703
- 5Bolt N90817003
- 7Clip N91100701
- 8Bracket 1J0971830J
- 8Bracket 1J0971830H
- 9Seal 3AA121345
- 9Seal 3C0121345AH
- 9Seal 3C0121345AJ
- 9Seal 3C0121345AM
- 9Seal 3C0121345AN
- 9Seal 3C0121345AP
- 10Seal 3C0121345L
- 10Seal 3C0121345AL
- 10Seal 3C0121345AT
- 15Air GuideLeft3C8121283C
- 15Air GuideLeft3C8121283B
- 16Air GuideRight3C8121284E
- 17Air Guide 3C8121330C
Vehicle fitment table1
Europe (1)
| Vehicle | Years | Pos. | Qty | Remark |
|---|---|---|---|---|
| Passat CC | 2011-2016 | 16 | 1 | CNNA |
Diagrams & fitment data powered by oemdiagrams.com
Air Guide is fitted on: Passat CC 2011-2016.
