433959845 Bellows
Special order item. Delivery time may vary.
About This Part
Discontinued by the manufacturer
This part number has been discontinued and can no longer be ordered. Contact us and we will look for an alternative.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VAG is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
13 vehiclesBellows — locate Bellows in the official exploded view and explore the surrounding assembly.
Parts in this assembly31
- 1Side MemberLeft533803101E
- 1Side MemberRight533803102D
- 2Wheel HousingRight533809102AP
- 2Wheel HousingLeft533809101AB
- 3Bracket 255955773
- 4SectionRight533809108
- 4SectionLeft533809107A
- 5Bungs N0200271
- 10CoverplateLeft533809409A
- 10CoverplateRight533809410A
- 10AReinforceRight533809626
- 10AReinforceLeft533809625
- 11SectionRight533809840A
- 12PartRight533809844C
- 12SectionLeft533809843A
- 13PartLeft533809847B
- 13PartRight533809848A
- 13PartRight533809848B
- 14Console 171803119G
- 15Strip 6X0959502
- 16Bolt N01024016
- 17Washer N0122283
- 18Edge Prot 823857281
- 25SillLeft533821511
- 25DWasher N0115402
- 25EScrew N0139713
- 25FPart 533853140
- 26TrimRight533821516A
- 26TrimLeft533821515A
- 27Prot Film 533821703
- 30Washer N0116644
Vehicle fitment table13
Europe (9)
| Vehicle | Years | Pos. | Qty |
|---|---|---|---|
| Scirocco | 1983-1989 | 20, 18, 27, 13, 15 | X |
| Jetta | 1981-1984 | 13, 15 | 2 |
| Audi 4000 | 1981-1984 | 22, 9 | 4 |
| Scirocco | 1981-1983 | 20, 18, 13, 15 | X |
| Audi 5000 | 1981-1982 | 18 | 2 |
| Scirocco | 1981-1981 | 20, 18 | X |
| PASSAT,-VARIANT/2 81 | 1980-1981 | 18 | X |
| Audi 4000 | 1979-1981 | 22, 9 | X |
| Audi 5000 | 1977-1979 | 13, 30 | 2 |
Other markets (4)
| Vehicle | Years | Pos. | Qty |
|---|---|---|---|
| Quantum | 1986-1988 | 18 | X |
| Quantum syncro | 1985-1988 | 18 | X |
| Quantum 86 | 1985-1986 | 18 | X |
| Quantum 85 | 1984-1985 | 18 | X |
Diagrams & fitment data powered by oemdiagrams.com
Bellows is fitted on: Scirocco 1983-1989; Jetta 1981-1984; Audi 4000 1981-1984; Scirocco 1981-1983; Audi 5000 1981-1982; Scirocco 1981-1981; PASSAT,-VARIANT/2 81 1980-1981; Audi 4000 1979-1981; Audi 5000 1977-1979; Quantum 1986-1988; Quantum syncro 1985-1988; Quantum 86 1985-1986; Quantum 85 1984-1985.
