Number 1 marks the part’s position in the exploded view (Audi A7 Sportback (2018-2025)).
Product overview
Genuine OEM Audi Fuel Tank, part number 4K8201060HD. Fits Audi A7 Sportback (2018-2025). Shown as position 1 in the fuel, exhaust and cooling diagram 435201000. Equipment code: 9M0.
Catalogue entry: CONTAINER.
Fitted with: 4K8201060N CONTAINER, 4K8201060AR CONTAINER, 4K8201060BK CONTAINER, 4K8201060GN CONTAINER, 4K8201060P CONTAINER, 4K8201060AT CONTAINER, 4K8201060BM CONTAINER, 4K8201060GP CONTAINER, 4K8201060ED CONTAINER, 1K0919133D seal ring.
Technical details
- Category
- Fuel System
- Diagram sheet
- Audi 435201000, position 1
- ETKA group
- 2 / 01 (201)
- Manufacturer
- Audi
- Product Type
- Genuine new auto parts
Specifications
As recorded in the manufacturer’s parts catalogue for this part number.
Equipment codes
- 9M0
PR codes identify the factory option a part belongs to; your vehicle’s are listed on the data sticker in the boot well or service booklet.
Why buy from WW Spares?
- ✓ Genuine OEM inventory sourced directly from factory networks
- ✓ Fitment support from workshop-seasoned parts specialists
- ✓ Global logistics with customs-ready documentation
Need help confirming compatibility? Talk to a specialist
Parts diagram & fitment
1 vehicleFuel Tank — locate 4K8201060HD Audi Fuel Tank in the official exploded view and explore the surrounding assembly.
Parts in this assembly42
- 1Container 4K8201060AR
- 1Container 4K8201060AT
- 1Container 4K8201060BK
- 1Container 4K8201060BM
- 1Container 4K8201060ED
- 1Container 4K8201060GN
- 1Container 4K8201060GP
- 1Container 4K8201060N
- 1Container 4K8201060P
- 2Module 4K0919087G
- 2Module 4K0919087H
- 2Module 4K0919087K
- 2Module 4K0919087P
- 3Flange 4K0201317B
- 3Flange 4K0201317E
- 4Sender 4K0919047
- 4Sender 4K0919047B
- 5Seal Ring 1K0919133D
- 6Part 1K0201375
- 8Fuel Line 4K0201220H
- 8Fuel Line 4K0201220J
- 15Strap 4K0201654D
- 16Screw N91165402
- 18Strap 4K0201654E
- 20Screw N91264001
- 21Strap 4K0201654F
- 24Plate 4K0201781A
- 28Heat Sh 4K0201308K
- 29Washer N90335004
- 30Bracket 4K0201710J
- 31Bolt N91042301
- 32Part 4K8201326H
- 32Part 4K8201326L
- 32Part 4K8201326N
- 33Closure 4K8201131D
- 33Closure 4K8201131E
- 35Control Unit 4K0906121A
- 35Control Unit 4K0906121B
- 35Control Unit 4K0906121C
- 35Control Unit 4K0906121D
- 36Retainer 4K0907731A
- 37Ut Hexagon Nut Self-locking Hexagon Nut N02300213
Compatible / alternative parts(1)
Vehicle fitment table1
Europe (1)
| Vehicle | Years | Pos. | Qty | PR |
|---|---|---|---|---|
| Audi A7 Sportback | 2018- | 1 | 1 | 9M0 |
Diagrams & fitment data powered by oemdiagrams.com
4K8201060HD Audi Fuel Tank is fitted on: Audi A7 Sportback 2018-.
