5WA820031A Heat Exchanger For High-Voltage Battery
- 5WA820031AThis pageNot stocked
Feb 2022 - 5WA820031BCurrent number
Special order item. Delivery time may vary.
About This Part
Superseded part number
This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VAG is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINShipping details
- Shipping weight
- 472 g
- Shipping size (L × W × H)
- 15 × 12 × 10.5 cm
- Customs (HS) code
- 87082990
Parts diagram & fitment
4 vehiclesHeat Exchanger For High-voltage Battery — locate Heat Exchanger For High-Voltage Battery in the official exploded view and explore the surrounding assembly.
Parts in this assembly40
- 1Condenser 5WA816411E
- 2Part 5Q0298403D
- 2Part 5Q0298403F
- 2Insert 5WA298403A
- 5Line 5Q0816721E
- 6Seal Ring 3D0260749C
- 7Seal Ring 4E0260749A
- 8Screw N10414402
- 9Bolt N10347103
- 11Line 5WA816741
- 11Line 5WA816741B
- 12Valve 3D0820855A
- 12Valve 8E0820855
- 13Part 5Q0816581
- 14Valve 8A0820855AA
- 15Seal Ring 7H0820896
- 16Part 4H0959126B
- 16Part 4H0959126C
- 17Seal Ring 4D0260749B
- 19Part 8R0260696A
- 19Part 8R0260696B
- 20Line 5WA816743J
- 22Part 5Q0816231
- 23Seal Ring 8E0260749C
- 24Seal Ring 4E0260749B
- 27Seal Ring 8A0260749AK
- 29Clip 5Q0820774
- 30Part 5Q2816738H
- 30Part 5Q2816738N
- 30Part 5Q1816738M
- 30Part 5Q1816738Q
- 33Collar Nut N01508210
- 34Bolt N91096801
- 37Heat Excha 5WA820031B
- 38Bolt N10653301
- 42Part N90994601
- 43Clip 1J0820774
- 44Screw N10657001
- 45Clip 1J0820774A
- 50Adapter 5WA816517
Vehicle fitment table4
Europe (4)
| Vehicle | Years | Pos. | Qty |
|---|---|---|---|
| Golf 2.0 BlueMotion | 2019-2024 | 37 | 1 |
| Octavia | 2019-2024 | 37 | 1 |
| Superb Combi | 2015-2024 | 37 | 1 |
| Passat saloon | 2014-2024 | 37 | 1 |
Diagrams & fitment data powered by oemdiagrams.com
Heat Exchanger For High-Voltage Battery is fitted on: Golf 2.0 BlueMotion 2019-2024; Octavia 2019-2024; Superb Combi 2015-2024; Passat saloon 2014-2024.
