Number 30 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Hex Collared Bolt, part number N10156009. This bolt features a hexagonal head with an integrated collar, providing a wider bearing surface for secure fastening. It is used in the engine assembly. Its precise manufacturing ensures proper fit and function, critical for maintaining the integrity of engine components.
Catalogue entry: BOLT M8X25 ×2.
Technical details
- Category
- Engine
- Customs (HS) code
- 73181588
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 3.4 × 1.8 × 1.8 cm
- Shipping weight
- 0.02 kg
Specifications
As recorded in the manufacturer’s parts catalogue for this part number.
- Thread
- M8x25 mm
Equipment codes
- G0L
- G1D
PR codes identify the factory option a part belongs to; your vehicle’s are listed on the data sticker in the boot well or service booklet.
Why buy from WW Spares?
- ✓ Genuine OEM inventory sourced directly from factory networks
- ✓ Fitment support from workshop-seasoned parts specialists
- ✓ Global logistics with customs-ready documentation
Need help confirming compatibility? Talk to a specialist
Parts diagram & fitment
49 vehiclesHex Collared Bolt — locate N10156009 Volkswagen Hex Collared Bolt | Genuine OEM in the official exploded view and explore the surrounding assembly.
Standard part (a norm part such as a bolt, nut or clip) — used across many models; the vehicle list shows where this exact number is fitted.
Parts in this assembly36
- 1Brake LevLeft7E1711301R
- 1Brake LevRight7E2711301Q
- 1Brake LevRight7E2711301R
- 1Brake LevLeft7E1711301Q
- 2Switch 1H0947561A
- 3Collar Nut N10609201
- 5TrimRight7H2711464A
- 5TrimLeft7E1711464A
- 6Handl 7E0711461
- 9Ut"hex Nut Self-locking With Washer Hex Nut N90286705
- 10Cable 7H0711476J
- 10CableLeft7H1711476G
- 10CableRight7H2711476F
- 10Cable 7H3711476G
- 10CableLeft7L1711476A
- 10CableRight7L2711476A
- 10Cable 7LA711476A
- 10Cable 7LA711476C
- 11Lever 7H0711481A
- 12Seal 7H0711489
- 13Seal 7H0711489A
- 15Bracket 7H3711403
- 15Bracket 7H3711495
- 16Pop Rivet N90437401
- 17BracketRight7H2711495B
- 17BracketLeft7H1711495A
- 20BracketLeft7E0711443A
- 20BracketRight7E0711444A
- 20Bracket 7H0711454
- 21Pop Rivet N90923602
- 22Bracket 7H0711453
- 25Abutment 7H0711804
- 26Bracket 7H0711249
- 27Spring 7H0711975D
- 28Bracket 701711367
- 31Part N90938701
Vehicle fitment table49
Europe (45)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| transport. multivan | 2019-2024 | 30 | 2 | PR:G0L,G1D | G0L |
| caravelle | 2019-2024 | 30 | 2 | PR:G0L,G1D | G0L |
| Single-cab transp. | 2019-2024 | 30 | 2 | PR:G0L,G1D | G0L |
| caravelle | 2015-2019 | 6 | 2 | ||
| Single-cab transp. | 2015-2019 | 6 | 2 | ||
| California Camper | 2015-2019 | 6 | 2 | ||
| new beetle | 2011-2016 | 10 | 6 | ||
| new beetle cabriolet | 2011-2016 | 10 | 6 | ||
| Crafter 35 panel | 2011-2016 | 7 | 2 | ||
| transp. caravelle | 2011-2015 | 26 | 1 | ||
| transp. dropside | 2011-2015 | 26 | 1 | ||
| California Camper | 2011-2015 | 26 | 1 | ||
| Golf | 2011-2013 | 10 | 6 | ||
| Cayenne | 2010-2018 | 18 | 1 | ||
| jetta | 2010-2014 | 10 | 6 | ||
| Panamera | 2009-2016 | 18 | 1 | 8 X 25 | |
| jetta variant | 2009-2014 | 10, 3 | 6 | ||
| transp. caravelle | 2009-2011 | 26, 30 | 1 | D4 | |
| transp. dropside | 2009-2011 | 26, 30 | 1 | D4 | |
| California Camper | 2009-2011 | 26, 30 | 1 | ||
| Jetta Vagon 08> | 2008- | 3 | 2 | ||
| golf 2.0 | 2008-2011 | 10 | 6 | ||
| Audi A6 2.7 TDI | 2008-2011 | 5 | 4 | ||
| Sharan | 2008-2010 | 19 | 4 | G0L | |
| transp. caravelle | 2008-2009 | 7, 19 | 5 | ||
| transp. dropside | 2008-2009 | 7, 19 | 5 | ||
| California Camper | 2008-2009 | 7, 19 | 5 | ||
| Touareg 08> | 2007- | 7 | 5 | TP7 | |
| TRANSPORTER GESCHL. 08 | 2007- | 7, 19 | 5 | ||
| TRANSPORTER OFFEN 08 | 2007- | 7, 19 | 5 | ||
| CAMPMOBIL-T5 08 | 2007- | 7, 19 | 5 | ||
| Cayenne | 2007-2010 | 18 | 2 | ||
| CRAFTER 06> | 2006- | 7 | 2 | ||
| Alhambra | 2006-2010 | 17 | 4 | ||
| TRANSPORTER/4MOTION 07 | 2006-2007 | 7, 19 | 5 | ||
| TRANSPORTER OFFEN (7J) 07 | 2006-2007 | 7, 19 | 5 | ||
| CAMPMOBIL (T5) 07 | 2006-2007 | 7, 19 | 5 | ||
| SHARAN/4MOTION | 2005- | 19 | 4 | G0L | |
| ALHAMBRA/4MOTION | 2005- | 17 | 4 | ||
| TRANSPORTER/4MOTION 06 | 2005-2006 | 7, 19 | 5 | BNZ,BPC | TM7 |
| TRANSPORTER 06 | 2005-2006 | 7, 19 | 5 | ||
| Touareg | 2005-2006 | 7 | 5 | T03,TP7 | |
| Audi A6/S6/Avant/qu. 05> | 2004- | 5 | 4 | ||
| CAMPMOBILE(T5) | 2004-2006 | 7, 19 | 5 | BNZ,BPC | TM7 |
| Cayenne | 2002-2006 | 18 | 1 |
Other markets (4)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| New Passat | 2011-2015 | 10 | 2 | ||
| DIES.-IND.-MOT.1,9>2,0 08> | 2007- | 3 | 3 | PR:JV0 | |
| Jetta "USA"05> | 2005- | 10 | 6 | ||
| MARINE-MOTOR 02> | 2002- | 22, 8 | 3 |
Diagrams & fitment data powered by oemdiagrams.com
N10156009 Volkswagen Hex Collared Bolt | Genuine OEM is fitted on: transport. multivan 2019-2024; caravelle 2019-2024; Single-cab transp. 2019-2024; caravelle 2015-2019; Single-cab transp. 2015-2019; California Camper 2015-2019; new beetle 2011-2016; new beetle cabriolet 2011-2016; Crafter 35 panel 2011-2016; transp. caravelle 2011-2015; transp. dropside 2011-2015; California Camper 2011-2015; Golf 2011-2013; Cayenne 2010-2018; jetta 2010-2014; Panamera 2009-2016; jetta variant 2009-2014; transp. caravelle 2009-2011; transp. dropside 2009-2011; California Camper 2009-2011; Jetta Vagon 08> 2008-; golf 2.0 2008-2011; Audi A6 2.7 TDI 2008-2011; Sharan 2008-2010; transp. caravelle 2008-2009; transp. dropside 2008-2009; California Camper 2008-2009; Touareg 08> 2007-; TRANSPORTER GESCHL. 08 2007-; TRANSPORTER OFFEN 08 2007-; CAMPMOBIL-T5 08 2007-; Cayenne 2007-2010; CRAFTER 06> 2006-; Alhambra 2006-2010; TRANSPORTER/4MOTION 07 2006-2007; TRANSPORTER OFFEN (7J) 07 2006-2007; CAMPMOBIL (T5) 07 2006-2007; SHARAN/4MOTION 2005-; ALHAMBRA/4MOTION 2005-; TRANSPORTER/4MOTION 06 2005-2006; TRANSPORTER 06 2005-2006; Touareg 2005-2006; Audi A6/S6/Avant/qu. 05> 2004-; CAMPMOBILE(T5) 2004-2006; Cayenne 2002-2006; New Passat 2011-2015; DIES.-IND.-MOT.1,9>2,0 08> 2007-; Jetta "USA"05> 2005-; MARINE-MOTOR 02> 2002-.
