N90749901 Locating Bolt
- N90749901This pageNot stocked
Jun 2011 - N90749902Discontinued
Apr 2025
Special order item. Delivery time may vary.
About This Part
Superseded part number
This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for SEAT is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
23 vehiclesLocating Bolt — locate Locating Bolt in the official exploded view and explore the surrounding assembly.
Parts in this assembly4
Vehicle fitment table23
Europe (22)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| TRANSPORTER/4MOTION 06 | 2005-2006 | 3 | 3 | G0 | |
| TRANSPORTER 06 | 2005-2006 | 3 | 3 | ||
| TRANSPORTER | 2003-2005 | 3 | 3 | ||
| LUPO/3L TDI | 2003-2005 | 6 | 3 | ||
| AROSA | 2003-2004 | 6 | 3 | ||
| SHARAN/4MOTION | 2002-2005 | 3 | 3 | ||
| ALHAMBRA/4MOTION | 2002-2005 | 3 | 3 | ||
| AUDI A2 | 2000-2005 | 11 | 3 | ||
| SHARAN/4MOTION | 2000-2002 | 3 | 3 | ||
| ALHAMBRA/4MOTION | 2000-2002 | 3 | 3 | ||
| CORDOBA/VARIO | 1999-2002 | 7, 15 | M6X8,6X36 | ||
| IBIZA | 1999-2002 | 7, 15 | M6X8,6X36 | ||
| POLO CLASSIC/VARIANT | 1999-2001 | 15 | 3 | ||
| POLO | 1999-2001 | 6 | 3 | 1AC | |
| LUPO/3L TDI | 1998-2003 | 6 | 3 | 1AC | |
| GOLF CABRIO | 1998-2001 | 15 | 2 | ||
| AROSA | 1997-2003 | 6 | 3 | ||
| POLO CLASSIC/VARIANT | 1996-1999 | 15 | |||
| IBIZA/CORDOBA/VARIO | 1996-1999 | 15 | 3 | ||
| CADDY-KOMBI/KASTEN | 1995-2003 | 15 | |||
| INCA (SEAT-VAN) | 1995-2003 | 15 | 3 | ||
| POLO | 1994-1999 | 6 | 3 |
Other markets (1)
| Vehicle | Years | Pos. | Qty | Remark | PR |
|---|---|---|---|---|---|
| Golf BR/US | 1999-2001 | 6 | 3 |
Diagrams & fitment data powered by oemdiagrams.com
Locating Bolt is fitted on: TRANSPORTER/4MOTION 06 2005-2006; TRANSPORTER 06 2005-2006; TRANSPORTER 2003-2005; LUPO/3L TDI 2003-2005; AROSA 2003-2004; SHARAN/4MOTION 2002-2005; ALHAMBRA/4MOTION 2002-2005; AUDI A2 2000-2005; SHARAN/4MOTION 2000-2002; ALHAMBRA/4MOTION 2000-2002; CORDOBA/VARIO 1999-2002; IBIZA 1999-2002; POLO CLASSIC/VARIANT 1999-2001; POLO 1999-2001; LUPO/3L TDI 1998-2003; GOLF CABRIO 1998-2001; AROSA 1997-2003; POLO CLASSIC/VARIANT 1996-1999; IBIZA/CORDOBA/VARIO 1996-1999; CADDY-KOMBI/KASTEN 1995-2003; INCA (SEAT-VAN) 1995-2003; POLO 1994-1999; Golf BR/US 1999-2001.
