Suction Line exploded parts diagram — Ibiza Reference · 2011-2012, position 5
Exploded view
Ibiza Reference · 2011-2012 · position 5Full diagram ↓
03C115251N

03C115251N Suction Line

£28.83
£23.83 excl. VAT
Supersession roadoldest to newest
  1. 03C115251HNot stocked
    Mar 2011
  2. 03C115251NThis pageNot stocked
    Apr 2012
  3. 03C115251AECurrent number
Current part number03C115251AEWhat the manufacturer supplies todayOrder
Availability: No longer supplied under this number

Special order item. Delivery time may vary.

About This Part

Superseded part number

This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.

Order Processing & Delivery

This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for SEAT is typically 3–8 business days before dispatch.

Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.

* Delivery times are estimates and may vary based on manufacturer availability and your location.

Verify Vehicle Fitment

To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.

Contact us with your VIN
Genuine OEM Parts
Direct from manufacturer
Secure Ordering
Safe and protected checkout

Parts diagram & fitment

8 vehicles

Suction Line — locate Suction Line in the official exploded view and explore the surrounding assembly.

Parts in this assembly14
Vehicle fitment table8

Europe (4)

VehicleYearsPos.QtyRemarkPR
Ibiza Reference2011-201251BTS,CAVE,
Audi A1 Sportback2010-201551TU0
Polo2009-201251D32
Fabia Jingrui2008-201451

Other markets (4)

VehicleYearsPos.QtyRemarkPR
Lavida2012-202151
bora2008-201651
POLO JIN QIN "CN"06>2006-51
POLO JIN QV "CN"06>2006-51

Diagrams & fitment data powered by oemdiagrams.com

Suction Line is fitted on: Ibiza Reference 2011-2012; Audi A1 Sportback 2010-2015; Polo 2009-2012; Fabia Jingrui 2008-2014; Lavida 2012-2021; bora 2008-2016; POLO JIN QIN "CN"06> 2006-; POLO JIN QV "CN"06> 2006-.
