Number 34 marks the part’s position in the exploded view.
Product overview
Genuine OEM Audi Exhaust Manifold Heat Shield, part number 06F129686. This essential component provides thermal insulation, protecting sensitive surrounding engine parts from the extreme heat produced by the exhaust manifold and turbocharger. It is positioned directly adjacent to the exhaust assembly. Weighing approximately 0.026 kg, this heat shield is made from specialized heat-resistant material. Choosing genuine OEM ensures effective thermal management and prevents heat-related damage to other engine components.
Technical details
- Category
- Exhaust
- Country of origin
- Germany
- Customs (HS) code
- 84219990
- Manufacturer
- Audi
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 9.5 × 8 × 1 cm
- Shipping weight
- 0.03 kg
Parts diagram & fitment
30 vehiclesHeat Insulation — locate 06F129686 Audi Exhaust Manifold Heat Shield | Genuine OEM in the official exploded view and explore the surrounding assembly.
Parts in this assembly(44)
- 1Turbo 06F145701HX
- 1Turbo 06F145701H
- 2Valve 06F906283F
- 3Valve 06H145710D
- 3Valve 06F145710G
- 4Hose 06F145718S
- 5Hose 06F145718Q
- 6Hose 06F145718R
- 7Bracket 06F103943F
- 8Bolt N0445203
- 9Oil Pipe 06F145778G
- 10Screw N01470213
- 11Screw WHT000223
- 12Seal Ring N0138514
- 15Support 06F145533B
- 16Screw N90292903
- 17Support 06F145536C
- 18Bolt N01024710
- 19Bolt N0903487
- 20Oil Pipe 06F145735F
- 20Oil Pipe 06F145735D
- 21Seal 06F145757H
- 23Seal 058145757A
- 24Screw N10086304
- 25Seal 06F253039F
- 26Collar Nut N90200201
- 27Seal 1K0253115AB
- 28Collar Nut N10286108
- 29Clip 1J0145769D
- 32Seal 06F145757F
- 33Screw N10347003
- 34Clip N90409601
- 34Clip N90739901
- 36Screw N91043801
- 37Seal Ring N0138302
- 38Clamp N10203601
- 39Bracket 06F145317H
- 40Cover 06F129597F
- 41Bolt N10265202
- 42Screw N91009701
- 43Screw N10459201
- 46Paste G052112A3
- 47Bolt N10546404
- 48Bolt N90444602
Diagrams & fitment data powered by oemdiagrams.com
06F129686 Audi Exhaust Manifold Heat Shield | Genuine OEM is fitted on: GOLF 2003-2005; Jetta "USA"05> 2005-; Passat/4Motion 2005-2007; JETTA 06> 2005-; Golf/Rabbit 2005-2007; EOS-Cabriolet-Coupe 2006-; JETTA 06> 2006-; GOLF VARIANT 07> 2007-; Golf/Rabbit 08> 2007-; Passat/4Motion 08 2007-; golf 2.0 2008-2011; Scirocco 2.0 2008-2014; EOS 2.0 2008-2010; jetta 2008-2011; Golf Cabriolet 2011-2016; Golf 2011-2013; Polo 2012-2014; Scirocco 2.0 2014-2017; Audi A3/S3/quattro 2005-2007; Audi TT Coupe/Roadster 08> 2007-; Audi A3/S3/Sportb./qu. 08 2007-; Audi A3 Sportback 2008-2013; Audi TTS Coupe 2.0 2010-2014; Audi A1 Sportback 2010-2015; ALTEA 2004-2006; TOLEDO 05> 2004-; LEON 06> 2005-; ALTEA 07> 2006-; Leon Stylance 2010-2012; OCTAVIA/COMBI/4X4 04> 2004-.
