1EA816544D Refrigerant Line
- 1EA816544BNot stocked
Jun 2020 - 1EA816544DThis pageNot stocked
Sep 2022 - 1EA816544FCurrent number
Special order item. Delivery time may vary.
About This Part
Superseded part number
This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for SEAT is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
11 vehiclesRefrigerant Line — locate Refrigerant Line in the official exploded view and explore the surrounding assembly.
Parts in this assembly37
- 1Drier 1EA816582
- 2Bracket 1EA815313
- 3Element 1EA815313B
- 4Collar Nut N90761103
- 6Heat Exch 9J1816132
- 7Bolt N10405604
- 8Valve 1EA816701A
- 8Valve 1EA816701D
- 9Valve 1EA816702A
- 9Valve 1EA816702C
- 9Valve 1EA816702D
- 10Expans Val 1EA816682A
- 10Expans Val 1EA816682D
- 11Expans Val 1EA816681A
- 11Expans Val 1EA816681C
- 11Expans Val 1EA816681D
- 12Bolt N10335206
- 14Bracket 1EA816571A
- 15Bush 1EA903127
- 16Grommet 1EA129669
- 17Bolt N10805001
- 18Line 1EA816531
- 19Seal 1EA959895
- 20Seal 1EA959895A
- 21Insert 4N0816561
- 22Part 4N0816564
- 24Line 1EA816532
- 28Line 1EA816540
- 32Line 1EA816542
- 36Line 1EA816543A
- 39Ring N10762301
- 41Part 4N0816563
- 42Line 1EA816544B
- 42Line 1EA816544F
- 45Sensor 4N0959126K
- 48Bolt WHT009366
- 48Screw WHT009534
Vehicle fitment table11
Europe (4)
| Vehicle | Years | Pos. | Qty |
|---|---|---|---|
| Audi Q4 Sportback | 2021-2022 | 42 | 1 |
| Enyaq | 2020- | 42 | 1 |
| ID.4 Pro | 2020-2023 | 42 | 1 |
| ID.3 Pro | 2019-2024 | 42 | 1 |
Other markets (7)
| Vehicle | Years | Pos. | Qty |
|---|---|---|---|
| Audi Q4 Sportback | 2022- | 42 | 1 |
| ID.6 X | 2021- | 42 | 1 |
| ID.3 | 2021- | 42 | 1 |
| ID.6 X | 2021- | 42 | 1 |
| Audi Q5 e-tron | 2021- | 42 | 1 |
| ID.4 X | 2020- | 42 | 1 |
| ID.4 | 2020- | 42 | 1 |
