About This Part
Superseded part number
This part number has been replaced. Order the current replacement shown above — the old number can no longer be supplied.
Order Processing & Delivery
This part is not stocked in our warehouse and will be ordered directly from the manufacturer upon purchase. Handling time for VAG is typically 3–8 business days before dispatch.
Handling time for VAG (VW / Audi / Seat / Cupra): 3–8 business days from order confirmation to dispatch (Monday–Friday). Shipping transit for your country is added on top — see handling times by brand and shipping options.
* Delivery times are estimates and may vary based on manufacturer availability and your location.
Verify Vehicle Fitment
To ensure this part is compatible with your vehicle, please contact us with your VIN (Vehicle Identification Number). Our technical team can verify the exact fitment before you place your order.
Contact us with your VINParts diagram & fitment
6 vehiclesSplit Pin — locate Split Pin in the official exploded view and explore the surrounding assembly.
Parts in this assembly35
- 1Bracket 281711249
- 1AClip 291711245A
- 1CClamp 211611403
- 1DScrew N0139502
- 5Part 111711323
- 6Part 281711325
- 7Press Spring 191711329
- 8Press Stud 113711333B
- 9Ratchet 171711339
- 11Part 281711341
- 12Ring N0124141
- 13Part 111711349
- 14Part N01100624
- 15Bellows 282711411
- 15Cover 321711411
- 17APart 294711471
- 17APart 293711473
- 18Part N0231531
- 18AWasher N01155811
- 19Ret Washer N0124362
- 20Part 293711475
- 20Pull Rod 281711475
- 20APart 294711475
- 21ALever 211711481A
- 22Lever 281711491
- 22APart 293711491
- 23Bear Br 282801234A
- 25AScrew N90094901
- 27Part N0339735
- 28Washer N01152520
- 31Washer N01152711
- 32Part N0125331
- 33Part 211711349
- 34Bolt N0163111
- 35Bracket 293711246
Vehicle fitment table6
Europe (5)
| Vehicle | Years | Pos. | Qty | Remark |
|---|---|---|---|---|
| LT, LT 4x4 (28-55) | 1989-1995 | 32 | 1 | |
| LT, LT 4x4 (28-55) | 1982-1989 | 32 | 1 | |
| Type 4 | 1968-1974 | 2 | 2 | |
| Type 2 | 1967-1979 | 2, 11 | 2 | 62,66,68 |
| VW 1200/1300 F>>118 | 1947-1977 | 8 | 4 |
Platform / generic diagrams (1)
| Vehicle | Years | Pos. | Qty | Remark |
|---|---|---|---|---|
| 644 platform | 25 | 1 |
Diagrams & fitment data powered by oemdiagrams.com
Split Pin is fitted on: LT, LT 4x4 (28-55) 1989-1995; LT, LT 4x4 (28-55) 1982-1989; Type 4 1968-1974; Type 2 1967-1979; VW 1200/1300 F>>118 1947-1977; 644 platform.
