Number 19 marks the part’s position in the exploded view.
Product overview
Genuine OEM Volkswagen Hex Shoulder Bolt, part number N10340802. This specialized bolt includes an unthreaded shoulder section, which is crucial for providing precise alignment and controlled clamping force when fastening engine components. The shoulder ensures that the bolt's clamping force is applied correctly and prevents over-stressing of the connected parts. Genuine OEM shoulder bolts are manufactured to exact dimensional specifications for critical assembly functions.
Technical details
- Category
- Engine
- Country of origin
- Germany
- Customs (HS) code
- 73181588
- Manufacturer
- Volkswagen
- Product Type
- Genuine new auto parts
- Shipping size (L × W × H)
- 3.1 × 1.3 × 1.3 cm
- Shipping weight
- 0.01 kg
Parts diagram & fitment
29 vehiclesBolt Hex Hd With Shoul (combi) — locate N10340802 Volkswagen Hex Shoulder Bolt | Genuine OEM in the official exploded view and explore the surrounding assembly.
Parts in this assembly(41)
- 1Cylinder Block 06D103101A
- 1Cylinder Block 06D103101D
- 1Crankcase 06F103011F
- 1Cylinder Block 06F103101
- 2Bolt N90130001
- 2Bolt WHT000134
- 3Cover N0119047
- 3Cover N01190710
- 4Lock 06F103623E
- 5Cover 036103113
- 9Vent 06F103154
- 9Vent 06B103154
- 10Part 026103139
- 11Seal 038103085E
- 12Flange 06B103151
- 12AFlange 06D103153B
- 14Bolt N90945002
- 15Seal D176404A2
- 16Flange 06A103171A
- 16Flange 06B103171B
- 19Part N0432072
- 20Sleeve 022103139
- 21Frame 06B103307C
- 21Frame 06B103307E
- 22Oil Sump 06F103601D
- 22Part 06F103601L
- 22Oil Sump 06F103601
- 23Bolt N90813202
- 24Bolt N90735604
- 29Spacer Pl 038103645C
- 30Tube 06D103634E
- 31Funnel 06F103663J
- 33Guide 06F103705B
- 34Lock 06D103623D
- 36Cover 06F103645A
- 37Coverplate 038103645A
- 38Bolt N0102085
- 39Washer N0122265
- 41Screw N90665001
- 43Lock 06F103623H
- 44Screw N90808702
Diagrams & fitment data powered by oemdiagrams.com
